Low-Temperature and Dust-Free Hammer Mill Machine
Low-Temperature and Dust-Free Hammer Mill Machine Usage:It's suitable for heat sensitive materials. Features:This system
Basic Info
Model NO. | MDZL-120 |
Customized | Customized |
Condition | New |
Warranty | 1 Year |
Object | Granules, Pellets |
Certificate | GMP cGMP FDA Approved |
Automation | Fully Automatic |
Function | Cone Mill |
Transport Package | Wooden Pakage |
Specification | 2000*600*1800 |
Trademark | Medigrade |
Origin | Shanghai, China |
Product Description
Low-Temperature and Dust-Free Hammer Mill Machine
Usage:It's suitable for heat sensitive materials. Features:This system can meet the requirements of low temperature, dust free and adjustment of granularity. The main measures are that when pulverizing materials, supplying the cold air at the same time, and control the speed of feeding by an adjustable, speed control screw feeder, thus, to make sure that the temperature of crushed material is lower than set value in process of pulverizing. Different granularity can be obtained by adjusting speed of rotary knife and replacing different sieve mesh. The powder flows in an airtight system in the whole process, which is collected by separating gas and solid, and then the dust-free exhaust is exhaled. Main technical parameters:
Production capacity(kg/h) | 40-200 |
Fineness of pulverization (mesh) | 80-120 |
Granularity of feed stock(mm) | <Φ12 |
Diameter of movable fluted disc (mm) | Φ300 |
Speed of main shaft (rpm) | 3800 |
Motor power (kW) | 7.5 |
Overall dimension (L×W×H) (mm) | 2000×600×1800 |
If you are interested in this, please contact me: Nana ZhangShanghai Medigrade IndustryWaigaoqiao Free Trade Zone, Shanghai,China. 200137 medigrade.en.made-in-china.com
